Ferdi Fittings, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of high-quality 90° Short Radius Elbows. Known for their precision engineering and durability, this company focuses on providing pipe fittings that adhere to international standards for various industrial applications. Their 90° Short Radius Elbows are expertly crafted to change the direction of pipelines in tight spaces while ensuring structural integrity. With a strong commitment to exceptional craftsmanship, Ferdi Fittings caters to a wide range of industries, including oil and gas, petrochemical, power generation, and water treatment, delivering reliable solutions that promote safe and efficient fluid flow through complex piping systems.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless Pipe 90° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 90° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 90° Short Radius Elbow
Typically made from carbon steel, stainless steel, or alloy steel based on specific application needs, the 90° Short Radius Elbow from Ferdi Fittings boasts high tensile strength, excellent corrosion resistance, and remarkable durability even under high-pressure and high-temperature conditions. Each fitting is carefully forged or welded to guarantee precise dimensions and mechanical reliability. Its hardness and impact resistance make it perfect for heavy-duty industrial applications, while the smooth internal surfaces help reduce friction and turbulence within the pipeline, ensuring a consistent flow and a longer service life in challenging environments.
Stainless Steel 90° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 90° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 90° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 90° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 90° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
Ferdi Fittings is a leading supplier of 90 Deg Short Redius Elbow in Istanbul, Turkey. We offer an extensive range of 90 Deg Short Redius Elbow, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 90 Deg Short Redius Elbow from Ferdi Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
90° Short Radius Elbows provide several key advantages, including their ability to fit into compact spaces where standard long radius elbows may not be suitable. Their design allows for quick directional changes in piping systems, making them ideal for installations with limited room. Despite their tighter bend, these elbows offer reliable flow control and minimal pressure loss in low-velocity systems. Made from durable materials like stainless steel and alloys, they offer corrosion resistance and long-lasting performance. Widely used in industries such as HVAC, chemical processing, and plumbing, they ensure efficient and effective flow management.
Yes, custom sizes for 90 Deg Short Redius Elbow are available at Ferdi Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@ferdifittings.com.
| NPS | O.D. D | Center-to-End A |
| 1 | 33.4 | 25 |
| 1 ¼ | 42.2 | 32 |
| 1½ | 48.3 | 38 |
| 2 | 60.3 | 51 |
| 2 ½ | 73 | 64 |
| 3 | 88.9 | 76 |
| 3 ½ | 101.6 | 89 |
| 4 | 114.3 | 102 |
| 5 | 141.3 | 127 |
| 6 | 168.3 | 152 |
| 8 | 219.1 | 203 |
| 10 | 273 | 254 |
| 12 | 323.8 | 305 |
| 14 | 355.6 | 356 |
| 16 | 406.4 | 406 |
| 18 | 457 | 457 |
| 20 | 508 | 508 |
| 22 | 559 | 559 |
| 24 | 610 | 610 |
These 90° Short Radius Elbows are commonly utilized in industries that require sharp directional changes in piping within confined spaces. They are particularly suited for oil and gas pipelines, chemical plants, petrochemical refineries, power plants, and water treatment systems. By connecting pipelines while minimizing space usage and maintaining flow efficiency, they play a crucial role in HVAC systems, marine applications, and industrial machinery where a compact design is essential. By offering a dependable solution for tight bends, Ferdi Fittings’ 90° Short Radius Elbows enhance system performance, lower maintenance requirements, and ensure safe and efficient operations.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
