Ferdi Fittings, located in Istanbul, Turkey, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel A105 Forged Fittings, catering to industries around the globe. With a strong focus on precision engineering and durability, the company delivers fittings that adhere to international standards, perfectly suited for demanding industrial applications. Ferdi Fittings prides itself on superior quality, dependability, and prompt delivery, making it a go-to partner for clients in the oil, gas, petrochemical, and power sectors. Their wide array of forged fittings guarantees leak-proof connections, impressive strength, and a long service life, making them a vital choice for critical piping systems.
| Forged Fittings Specifications | ASTM A105/ ASME SA105 |
|---|---|
| Carbon Steel A105 Forged Fittings size | 1/8” NB to 4” NB (Socket weld & Screwed-Threaded) |
| Carbon Steel A105 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Carbon Steel A105 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A105 Carbon Steel A105 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Carbon Steel A105 Forged Fittings Thread | NPT, BSPT, BSPP |
| Carbon Steel A105 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Carbon A105 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A105 | 0.35 | 0.10–0.35 | 0.60–1.05 | 0.035 | 0.040 | 0.12 | 0.40 | 0.30 | 0.40 | 0.08 |
| Grade | Yield Strength, Min (MPa) | Tensile Strength, Min (MPa) | Elongation, min, % |
| A105 | 250 | 485 | 30 |
The Carbon Steel A105 Forged Fittings are crafted from high-quality carbon steel, incorporating elements like carbon, manganese, phosphorus, and sulfur in carefully controlled amounts. These fittings boast excellent tensile strength, yield strength, and hardness while still offering good ductility and toughness. With outstanding mechanical properties, they are built to resist high-pressure and high-temperature environments. Their sturdy design enhances performance in both welded and threaded applications, making them ideal for critical piping systems. Plus, they provide good machinability and weldability, ensuring easy installation and maintenance across various industrial operations.
| ASTM A105 / A105M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Carbon Steel A105 Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Carbon Steel A105 fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| Products | Size | |
|---|---|---|
| ASTM A105 Carbon Steel 90° Elbow | ASTM A105 Carbon Steel 45° Elbow | Sizes 1/8″– 4″ Pressure Ratings – 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| ASTM A105 Carbon Steel Forged Tee | ASTM A105 Carbon Steel Union | |
| ASTM A105 Carbon Steel Forged Cross | ASTM A105 Carbon Steel Insert | |
| ASTM A105 Carbon Steel Screwed Bushing | ASTM A105 Carbon Steel Threaded Pipe Nipple | |
| ASTM A105 Carbon Steel Forged Socket weld Cap | ASTM A105 Carbon Steel Screwed Coupling | |
| ASTM A105 Carbon Steel Forged Plug | ASTM A105 Carbon Steel Street Elbow | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Carbon Steel A105 Forged Fittings offer several advantages, making them ideal for industrial applications. They provide excellent strength and durability, ensuring long service life under high-pressure and high-temperature conditions. Their corrosion resistance makes them suitable for harsh environments, including oil, gas, and chemical industries. With exceptional machinability and weldability, they are easy to install and maintain. These fittings deliver cost-effective performance due to their affordability and extended reliability. Additionally, they comply with international standards, ensuring safety, quality, and compatibility with various piping systems.
Carbon Steel A105 Forged Fittings from Ferdi Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Carbon Steel A105 Forged Fittings are available at Ferdi Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@ferdifittings.com.
Carbon Steel A105 Forged Fittings find extensive use in industries that demand high-performance piping components for fluid and gas transmission under extreme conditions. They are commonly utilized in oil and gas pipelines, petrochemical plants, refineries, power generation, and shipbuilding sectors. Their ability to endure high pressure and temperature makes them perfect for steam, water, and chemical processing systems. These fittings are also favored in construction, mechanical equipment, and heavy engineering applications. Their durability, leak-proof design, and reliability make them essential for industries where strength and efficiency are paramount.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
