Ferdi Fittings is a top manufacturer and supplier of Incoloy Buttweld Fittings in Istanbul, Turkey. Incoloy, a group of nickel-iron-chromium alloys, is well-known for its ability to resist oxidation, carburization, and high-temperature corrosion. These buttweld fittings come in various grades to meet different industrial needs, including harsh chemical and thermal environments. Ferdi Fittings produces Incoloy buttweld fittings like elbows, tees, reducers, and caps, following ASTM/ASME standards. With careful engineering and strict quality checks, Ferdi Fittings offers durable, leak-proof, and corrosion-resistant Incoloy fittings for industries that require high strength and long-lasting reliability in tough conditions.
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Incoloy alloys typically contain 30 to 46% nickel, 19 to 23% chromium, 30 to 46% iron, and smaller amounts of molybdenum, titanium, aluminum, and copper, depending on the grade. Mechanical properties include a tensile strength of approximately 550 to 760 MPa, yield strength of around 240 to 350 MPa, elongation of about 30 to 40%, and hardness of approximately 150 to 200 HB. These alloys show excellent resistance to oxidation, carburization, and corrosion from chlorides at high temperatures. Incoloy maintains toughness and ductility over a wide temperature range, making it a good choice for demanding and high-temperature applications. Its strong weldability and durability ensure dependable performance in tough industrial settings.
Ferdi Fittings is a leading supplier of Incoloy Buttweld Pipe Fittings in Istanbul, Turkey. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy Pipe Fittings from Ferdi Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy Buttweld Fittings offer numerous advantages, making them a preferred choice across industries. Their excellent corrosion resistance ensures durability in harsh environments, including high temperatures and chemical exposure. These fittings provide superior mechanical strength, reducing the risk of failure under pressure. The seamless construction enhances flow efficiency and eliminates weak points, ensuring long-term reliability. Incoloy’s resistance to oxidation and stress-corrosion cracking adds to its versatility, making it ideal for marine, chemical, and power industries. Easy to weld and install, these fittings also ensure leak-proof and robust connections.
Yes, custom sizes for Incoloy Pipe Fittings are available at Ferdi Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@ferdifittings.com.
Incoloy Buttweld Fittings are commonly used in chemical processing, power generation, and marine industries. They are perfect for piping systems that handle sulfuric acid, phosphoric acid, and seawater. In thermal power plants, they perform reliably in boilers, superheaters, and heat exchangers that are exposed to high temperatures. The petrochemical industry uses them in reactors and piping systems that face oxidizing and reducing conditions. In marine environments, Incoloy fittings resist corrosion from seawater, making them essential for offshore platforms. With solid resistance to stress corrosion cracking and scaling, Incoloy buttweld fittings offer safe and long-lasting service in harsh conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
