Ferdi Fittings, located in Istanbul, Turkey, has built a solid reputation as a reliable manufacturer and supplier of top-notch Incoloy 825 Forged Fittings, catering to industries around the globe with a focus on excellence and dependability. Thanks to their state-of-the-art production facilities and dedication to meeting international standards, the company produces forged fittings that excel in even the toughest environments. Incoloy 825 is highly valued for its remarkable resistance to corrosive and reducing agents, making it a perfect choice for challenging service conditions. Ferdi Fittings prioritizes precision engineering, rigorous quality control, and prompt delivery, positioning itself as a go-to partner for industries that need robust and high-performance forged fittings for their critical operations.
| ASTM B564 Incoloy Alloy 825 Forged Fittings Specification | |
|---|---|
| Specifications | ASTM B564 / ASME SB564 |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8″ NB to 4″ NB (Socketweld & Screwed-Threaded) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT |
| Gr.825 Incoloy Alloy Forged Pipe Fittings Chemical Composition | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Grade | Ni | C | Fe | Si | Mn | S | Al | Ti | Cu | Cr | Mb |
| Incoloy 825 | 38.0 – 46.0 | 0.05 max | 22.0 min | 0.5 max | 1.0 max | 0.03 max | 0.2 max | 0.6 – 1.2 | 1.5 – 3.0 | 19.5 – 23.5 | 2.5 – 3.5 |
| Incoloy 825 Forged Fittings Mechanical Properties | |||||
|---|---|---|---|---|---|
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000, MPa -550 | Psi – 32,000, MPa – 220 | 30 % |
| Incoloy ASTM B564 Forged Fittings Equivalent Grades | ||||||||
|---|---|---|---|---|---|---|---|---|
| STANDARD | UNS | WNR NO. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 825 | N08825 | 2.4858 | NFE30C20DUM | NiCr21Mo | NCF 825 | NA 16 | ЭП703 | XH38BT |
Incoloy 825 Forged Fittings are primarily made up of nickel, iron, and chromium, with added elements like molybdenum, copper, and titanium that boost their corrosion resistance. This alloy boasts impressive mechanical properties, including high tensile and yield strength, along with exceptional toughness and durability. It stands out for its ability to resist stress corrosion cracking, oxidation, and pitting in harsh settings. The blend of outstanding metallurgical stability and mechanical strength guarantees that these fittings deliver long-lasting performance in both high-temperature and corrosive industrial environments.
Ferdi Fittings is a leading supplier of Incoloy 825 Forged Fittings in Istanbul, Turkey. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 825 Forged Fittings from Ferdi Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 825 forged fittings offer outstanding resistance to corrosion, especially in acidic and oxidizing environments, making them ideal for chemical processing and marine applications. Their high nickel content prevents stress-corrosion cracking, while molybdenum and copper enhance resistance to pitting and crevice corrosion. These fittings maintain excellent mechanical strength and stability across a broad temperature range. They are also highly durable and versatile, supporting easy fabrication and welding. Reliable and long-lasting, Incoloy 825 forged fittings are perfect for demanding industries like oil and gas, pollution control, and power generation systems.
Yes, custom sizes for Incoloy 825 Forged Fittings are available at Ferdi Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@ferdifittings.com
Incoloy 825 Forged Fittings find their place in various industries where strength and resistance to harsh conditions are essential. They’re commonly used in chemical processing plants, marine sectors, and pollution control equipment due to their ability to withstand sulfuric and phosphoric acids. Oil and gas refineries rely on them heavily for piping systems that face seawater and sour gas conditions. Moreover, they play a crucial role in nuclear fuel reprocessing, pickling operations, and heat exchangers. Their capacity to endure high-pressure and high-temperature applications makes them vital in critical industries that demand reliable and durable forged fittings.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
