Ferdi Fittings is a top manufacturer and supplier of Monel Buttweld Fittings in Istanbul, Turkey. Monel, a nickel-copper alloy, is known for its excellent corrosion resistance, toughness, and durability in harsh environments. These buttweld fittings are made to ASTM/ASME standards, ensuring reliable performance in both high-temperature and high-pressure conditions. Ferdi Fittings produces a wide range of Monel buttweld fittings, including elbows, tees, reducers, and caps, with precise engineering for leak-proof and durable service. Industries worldwide rely on Ferdi Fittings for high-quality Monel fittings that provide long-term reliability in challenging industrial applications.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Type : Seamless / Welded / Fabricated
Schedule : Sch 5 TO Sch XXS.
Thickness : 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc.
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
Monel alloys generally consist of 63-70% nickel, 28-34% copper, and small amounts of iron, manganese, silicon, and carbon. These alloys show excellent resistance to seawater, acidic, and alkaline environments. Mechanical properties include a tensile strength of about 550-620 MPa, a yield strength of around 240-345 MPa, an elongation of about 30-40%, and hardness between 120-180 HB. Monel retains toughness across a wide range of temperatures, including cryogenic conditions. It offers great resistance to stress corrosion cracking and pitting, making it one of the most reliable nickel alloys for harsh marine and chemical processing environments.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Ferdi Fittings is a leading supplier of Monel Buttweld Fittings in Istanbul, Turkey. We offer an extensive range of Monel Buttweld Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN |
| Monel | 2.4375 | N05500 | – | – | – | – | – |
Choose Monel Buttweld Fittings from Ferdi Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel Buttweld Fittings offer numerous advantages, including exceptional corrosion resistance, particularly in seawater, acidic, and alkaline environments. They are highly durable, resisting pitting, crevice corrosion, and stress corrosion cracking, which ensures reliable performance in harsh conditions. These fittings also retain their strength and mechanical properties at elevated temperatures, making them ideal for high-pressure and high-temperature applications. Monel Buttweld Fittings are also known for their excellent weldability, machinability, and long-term reliability. Their versatility and ability to withstand aggressive environments make them a preferred choice for marine, chemical, and industrial applications.
Yes, custom sizes for Monel Buttweld Fittings are available at Ferdi Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@ferdifittings.com
Monel Buttweld Fittings are widely used in marine, chemical, and petrochemical industries. Their resistance to seawater corrosion makes them essential for offshore platforms, heat exchangers, and seawater piping systems. In chemical processing, they are used in equipment that handles sulfuric acid, hydrofluoric acid, and alkalis. They also find applications in valves, pumps, and condensers where reliability under pressure is critical. Aerospace and oil and gas industries use Monel fittings for their excellent strength and durability in extreme environments. These fittings ensure safe, leak-proof connections for long service life in aggressive operating conditions.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
