Ferdi Fittings, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of high-quality Monel Forged Fittings, designed to meet a variety of industrial demands. Known for their precision engineering and durability, Ferdi Fittings offers products that adhere to strict international standards. Their Monel Forged Fittings are expertly crafted to provide outstanding corrosion resistance, strength, and reliability, even in the harshest environments. Catering to sectors like chemical processing, marine, and oil and gas, Ferdi Fittings merges cutting-edge manufacturing techniques with thorough quality control, delivering components that boost system efficiency, safety, and longevity, making them a trusted choice around the globe.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
Monel Forged Fittings are primarily made up of nickel (at least 63%) and copper, along with trace amounts of iron, manganese, and silicon. This distinctive alloy composition gives them remarkable corrosion resistance in both acidic and alkaline settings. The fittings boast impressive mechanical properties, such as high tensile and yield strength, toughness, and good elongation. Monel’s ability to resist stress corrosion cracking and pitting makes these fittings perfect for extreme conditions. They also retain their strength at elevated temperatures, ensuring reliable performance in demanding applications where both structural integrity and corrosion resistance are essential.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Ferdi Fittings is a leading supplier of Monel Forged Fittings in Istanbul, Turkey. We offer an extensive range of Monel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Choose Monel Forged Fittings from Ferdi Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel Forged Fittings offer several key advantages, including exceptional corrosion resistance, particularly in seawater and acidic environments. Their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking makes them ideal for harsh conditions, such as marine and chemical processing applications. Monel fittings maintain their strength and integrity at elevated temperatures, offering superior durability in high-stress environments. They also possess excellent weldability and machinability, making installation and customization easier. With their long-lasting performance and ability to withstand extreme conditions, Monel Forged Fittings provide reliable solutions for critical industrial applications.
Yes, custom sizes for Monel Forged Fittings are available at Ferdi Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@ferdifittings.com
Monel Forged Fittings find extensive use in industries that require resistance to seawater, acids, and high temperatures. Typical applications include chemical processing plants, desalination units, marine equipment, and oil and gas pipelines. They are perfect for valve bodies, flanges, elbows, tees, and reducers, providing dependable flow control and connectivity in challenging environments. The durability of these fittings means minimal maintenance and a long service life, making them suitable for both offshore and onshore projects. Additionally, they are employed in power generation, pulp and paper, and pharmaceutical industries, where corrosion resistance and mechanical strength are crucial.
